| 產品圖片 | 系列 | 輸出頻率 | 輸出方式 | 輸出數量 | 輸入方式 | 工作電壓 | 工作溫度 | 抖動 | 產品特點 | 樣品申請 | 規格書 |
|---|---|---|---|---|---|---|---|---|---|---|---|
品列表.png?U1lLQjIzSDA45Lqn5ZOB5YiX6KGoLnBuZw==)
|
DC~1GHz@LP-HCSL
DC~350MHz@LVCMOS |
LP_HCSL
LVCMOS |
8路差分
1路單端 |
3 Input Reference (Two Differential@DC~1Ghz/ One crystal@8~50Mhz)
|
1.8V~3.3V
|
-40°C~+85°C
|
34fs Typ. RMS(12KHz~20MHz)@156.25MHz LP_HCSL
|
Supports LP-HCSL differential outputs only; Ultra-low jitter and high PSRR (?76dBc)
|
|
||
|
|
DC~1GHz@LP-HCSL
DC~350MHz@LVCMOS |
LP_HCSL
LVCMOS |
8路差分
1路單端 |
3 Input Reference (Two Differential@DC~1Ghz/ One crystal@8~50Mhz)
|
1.8V~3.3V
|
-40°C~+85°C
|
34fs Typ. RMS(12KHz~20MHz)@156.25MHz LP_HCSL
|
Glitch-Free Switchover; Supports LP-HCSL differential outputs only; Ultra-low jitter and high PSRR (?76dBc)
|
|
||
品列表.png?U1lLQjIzRjA45Lqn5ZOB5YiX6KGoLnBuZw==)
|
DC~3.1GHz
|
LVDS
LVPECL LPHCSL LVCMOS |
8路差分
1路單端 |
3Input Reference (Two Differential@DC~3.1Ghz/ One crystal@8~50Mhz)
|
1.8V~3.3V
|
-40°C~+85°C
|
34fs Typ. RMS(12KHz ~ 20MHz)@156.25MHz LP_HCSL
|
Ultra-low additive jitter and output skew (<50ps)
|
|
||
|
|
DC~3.1GHz
|
LVDS
LVPECL LPHCSL LVCMOS |
8路差分
1路單端 |
3Input Reference (Two Differential@DC~3.1Ghz/ One crystal@8~50Mhz)
|
1.8V~3.3V
|
-40°C~+85°C
|
34fs Typ. RMS(12KHz ~ 20MHz)@156.25MHz LP_HCSL
|
Glitch-Free Switchover; Ultra-low additive jitter and output skew (<50ps)
|
|
||
|
DC~3.1GHz
|
LVDS
LVPECL LPHCSL LVCMOS |
10路差分
1路單端 |
LVDS
LVPECL LPHCSL LVCMOS 外部XTAL: 8~50MHz |
1.8V~3.3V
|
-40°C~+85°C
|
31fs Typ. @156.25MHz 3.3V LVPECL
|
Glitch-Free Switchover(@SYKB23F10G)
Ultra-low latency and skew |
|
||
|
|
DC~3.1GHz
|
LVDS
LVPECL LPHCSL LVCMOS |
10路差分
1路單端 |
LVDS
LVPECL LPHCSL LVCMOS 外部XTAL: 8~50MHz |
1.8V~3.3V
|
-40°C~+85°C
|
31fs Typ. @156.25MHz 3.3V LVPECL
|
Ultra-low latency and skew
|
|
